Description
Air Motor Output Power @ Maximum Speed 5 hp Maximum Torque 132 in-lb No Load Speed 2 500 RPM Maximum Flow Rate 175 cfm Shaft Diameter 7/8 in Shaft Length 2 1/8 in Mount Type Face Inlet Size 1/2 in Air Inlet Type NPT Rotation CW/CCW Housing Material Cast Iron Shaft Material Grade Not Applicable Bearing Protection Not Applicable Maximum Operating Pressure 100 psi Includes Muffler Keyway Width 1/8 in Weight 28 lb Housing Material Grade G2500 Housing Material Finish Painted- Alternate Part Numbers- 33K664- 8AMNRV28A- 33K664
Features
Extra Information
Processing Time:
2-3 days
Specs
Country of Origin:
US
Manufacturer Name:
8AM-NRV-28A
Manufacturer Part Number:
GAST
