Description
Sprocket Bore Diameter 1 in For Chain Pitch 5/8 in For Number of Strands Single Hub Type One Side Material Steel Maximum Bore Diameter 1 in Number of Teeth 30 Outside Diameter 6.
32 in Pitch Diameter 5.
979 in Bore Type Fixed Chain Number 50 Finish Black Oxide Hub Diameter 3 1/4 in Hub Projection 0.
907 in Includes Set Screws Keyway Yes Keyway Depth 1/8 in Keyway Width 1/4 in Length through Bore 1 1/4 in Number of Set Screws 2- Alternate Part Numbers- 36GD43- 50BS30HX1- 36GD43
Features
Extra Information
Processing Time:
2-3 days
Specs
Country of Origin:
CN
Manufacturer Name:
50BS30H X 1
Manufacturer Part Number:
TRITAN
