Description
Spiral Wound Flange Gasket For Flange ANSI Class 150 For Pipe Size 5 in Inside Diameter 6 1/8 in Outside Diameter 7 3/4 in Thickness 3/16 in Rim Stripe Color Gray Outside Rim Color Green Filler Material Graphite Outer Ring Material Carbon Steel Minimum Operating Temperature -400 Degrees F Maximum Operating Temperature 842 Degrees F Spiral Winding Material Stainless Steel Spiral Winding Stainless Steel Grade 316L Inner Ring Material None- Alternate Part Numbers- 38R325- CG- 38R325
Features
Extra Information
Processing Time:
2-3 days
Specs
Country of Origin:
CN
Manufacturer Name:
CG
Manufacturer Part Number:
FLEXITALLIC
