Description
Roller Chain Sprocket Bore Diameter 1/2 in For Chain Pitch 3/8 in For Number of Strands Single Hub Type One Side Material Steel Maximum Bore Diameter 1/2 in Number of Teeth 10 Outside Diameter 1.
38 in Pitch Diameter 1.
214 in Bore Type Fixed Chain Number 35 Finish Black Oxide Hub Diameter 1 in Hub Projection 0.
582 in Includes Set Screws Keyway No Keyway Depth Not Applicable Keyway Width Not Applicable Length through Bore 3/4 in Number of Set Screws 2- Alternate Part Numbers- 55VX89- 35BS10HX12- 55VX89
Features
Extra Information
Processing Time:
2-3 days
Specs
Country of Origin:
CN
Manufacturer Name:
35BS10H X 1/2
Manufacturer Part Number:
TRITAN
