Office 300 PRO INSTALLED

Technical Specifications

• Coverage Area: Up to 15,000 sq. ft.
• Amplifier Gain: 72 dB (maximum allowed by the FCC)
• Frequencies Supported:
  • Band 12/17 (700 MHz)
  • Band 13 (700 MHz)
  • Band 5 (850 MHz)
  • Band 4 (1700/2100 MHz)
  • Band 25/2 (1900 MHz)
• Power Supply: 110-240V AC, 50-60 Hz, 20 W
• Connectors: F-Female, 75 Ohm impedance
• Outside Antenna: New omni-directional antenna (25” long, 9 dBi peak gain)
• Inside Antennas: Two slim, low-profile dome antennas
• Dimensions: 14.25 x 10.75 x 2.25 inches (booster)
• Weight: 7.7 lbs.

Specifications

• SKU 479047
• UPC 810005965156
• Condition New
• Impedance 75 ohm
• Gain (Up/Down) 72 dB
• Max Coverage Up to 15,000 sq ft
• Frequencies Supported 700MHz, 800MHz, 1700/2100MHz, 1900MHz
• Outside Antenna Type Omnidirectional
• Inside Antenna Type Omnidirectional
• Number of Inside Antennas 2 Inside Antennas
• Power Requirements 110-240V AC, 50-60 Hz, 20 W
• Connector F-Female
• Specific Frequencies Supported 698 - 716 MHz / 728 - 746 MHz, 776 - 787 MHz / 746 - 757 MHz, 824 - 849 MHz / 869 - 894 MHz, 1710 - 1755 MHz / 2110 - 2155 MHz, 1850 - 1915 MHz / 1930 - 1995 MHz
