Description
Fully Tested - Certified pre-owned product with a signed and stamped Apex Waves Test Report, specific to serial numbers and shipment date. Includes NI Certificate of Conformity, manuals and datasheets. (If other certs are required, please request specific documentation). Fully tested by LabVIEW-trained technicians using OEM (NI) software & Fluke 5700A Calibrator, inspected with counterfeit protection, authenticated per serial number through the NI Instrument Certificate Generator portal. Cleaned & securely packed in custom packaging: static-sealed bubble bags, boxed, and labeled in packaging comparable to the original manufacturer’s standard. Backed by Apex Waves 2-Year Warranty (the longest warranty in the market). Ask about our new Care Packages for all NI Systems for calibration, maintenance & extended warranty!
Technical Data
| Absolute accuracy of the AI (microV): | 980 |
|---|---|
| Bustype: | PCI |
| Connection type front: | 68-Pin, Weiblich VHDCI |
| Max. Number of differential analogue input channels: | 16 |
| Max. Number of ground-related analogue input channels: | 32 |
| Max. Update rate (MS/s): | 2.86 |
| Measured electrical signal: | Voltage |
| Measurements per second/sampling rate (MS/s): | 0.625 |
| Number of analogue output channels: | 4 |
| Number of bidirectional digital channels: | 48 |
| Number of counters/timers: | 2 |
| Protectively coated: | No |
| Resolution of the analogue input: | 18 bit |
| Samplerate: | 625 kS/s |
| Simultaneous scanning: | No |
| Supported input power: | Bus Powered |
| Voltage measuring range of the analogue input (V): | -10 V bis 10 V, -2 V bis 2 V, -0.1 V bis 0.1 V, -0.5 V bis 0.5 V, -0.2 V bis 0.2 V, -5 V bis 5 V, -1 V bis 1 V |
