DAYTON 31TR73 - MTR CS/CR ODP 3/4 HP 1725 56 EFF 81.
8 - GENERAL PURPOSE MOTOR CAPACITOR-START/CAPACITOR-RUN OPEN DRIPPROOF 3/4 HP NAMEPLATE RPM 1725 56 FRAME VOLTAGE 115/208-230 60 HZ 1 PHASE 6.
6/3.
5-3.
3 FULL LOAD AMPS NUMBER OF SPEEDS 1 MOUNTING BASE MOTOR MOUNTING POSITION ALL ANGLE MOTOR THERMAL PROTECTION AUTO INSULATION CLASS B 1.
25 SERVICE FACTOR BALL BEARINGS FRAME MATERIAL ROLLED STEEL MAX AMBIENT TEMP 40 DEGREES C CW/CCW ROTATION OVERALL LENGTH 13-1/8 IN.
MOTOR SHAFT DESIGN KEYED - EQUAL TO G9096981
Features
Extra Information
Mandatory & Preferred Sources:
- Green Products
Specs
Manufacturer Name:
DAYTON
Manufacturer Part Number:
31TR73
