Description
HVAC Motor Motor Design Capacitor-Start 1/4 HP No of Speeds 1 Voltage 460V AC Motor Shaft Rotation CW/CCW 48Y Frame Motor Enclosure Design Totally Enclosed Air-Over Stud Motor Mounting Type Motor Mounting Position All Angle Shaft Dia 1/2 in Shaft Length 6 in Motor Thermal Protection Auto Max Ambient Temp 60 Degrees C Nameplate RPM 1 075 HVAC/R Condenser Fan Full Load Amps 0.
80 Ins.
Class B Motor Bearings Ball Overall Length 11 1/8 in- Alternate Part Numbers- 56JC91- 3736
Features
Extra Information
Processing Time:
2-3 days
Specs
Country of Origin:
MX
Manufacturer Name:
3736
Manufacturer Part Number:
U.S. MOTORS
