Description
Motion Control Coupling Angular Misalignment 3 Degrees Bore Diameter 1 8 mm Bore Diameter 2 5 mm Coupling Material Stainless Steel Coupling Outside Diameter 19.
1 mm Maximum Speed 6 000 RPM Maximum Torque 3.
51 N-m Axial Motion 0.
13 mm Overall Length 31.
8 mm Parallel Misalignment 0.
2 mm System of Measurement Metric Different Bore Sizes Yes Torsional Stiffness 1.
18 N-m/Deg Bore Type Round Shaft Locking Type Set Screw Number of Beams 6 Length Through Bore 2 15.
4 mm
