Description
MCKINNEY TA2314 4 1/2 X 4 1/2 32D - HINGE FULL MORTISE SLEEVE BEARING - HINGE HOSPITAL TIP NO MOUNTING FULL MORTISE BEARING TYPE SLEEVE PIN TYPE REMOVABLE FINISH DULL STAINLESS STEEL HEIGHT 4-1/2 IN.
WIDTH 4-1/2 IN.
LEAF THICKNESS 0.
134 IN.
HOLES PER LEAF 4 CORNERS SQUARE MATERIAL STAINLESS STEEL COLOR SILVER FRAME LEAF LENGTH 4-1/2 IN.
FRAME LEAF WIDTH 2-1/4 IN.
DOOR THICKNESS 1-3/4 IN.
PIN MATERIAL STEEL RANGE OF MOTION 270 DEGREES HARDWARE INCLUDED STANDARDS ANSI/BHMA 156.
7 - EQUAL TO G9784031
Features
Specs
Manufacturer Name:
MCKINNEY
Manufacturer Part Number:
TA2314 4 1/2 X 4 1/2 32D
