Description
H8109 Flange Mount Relay Base Shape Square Coil Voltage 24V AC Contact Form SPST-NO Current Rating 10 A Electrical Connection Quick-Connect Flat Pin Width 0.
187 in Number of Pins 4 Sealing Flux Protection Status Indicator No Indicator Contact Rating (AC) 10 A @ 250V Contact Rating (DC) 10 A @ 30V Horsepower @ 120V AC 1/3 hp Horsepower @ 240V AC 1/2 hp Mounting Style Top Flange Body Depth 1.
16 in Body Height 1.
73 in Body Width 0.
52 in Coil Resistance 260 ohm- Alternate Part Numbers- 6C890- G2R1ATAC24- 6C890
Features
Extra Information
Processing Time:
2-3 days
Specs
Country of Origin:
MY
Manufacturer Name:
G2R-1A-T-AC24
Manufacturer Part Number:
OMRON
