Description
General Purpose Motor Three Phase Motor Design 3-Phase 7 1/2 HP Nameplate RPM 1 182 No of Speeds 1 Voltage 230/460V AC Full Load Amps 20.
2/10.
1 A 254T Frame Usable @ 208V No Usable @ 200V No Hz 60 Hz Motor Service Factor 1.
15 Max Ambient Temp 104 Degrees F Motor Thermal Protection None Duty Cycle Continuous Ins.
Class F NEMA Design B Motor Enclosure Design Open Dripproof Motor Shaft Rotation CW/CCW Motor Mounting Type Rigid Base Motor Mounting Position Horizontal- Alternate Part Numbers- 454X51- 254TTDBD6076- 454X51
Features
Extra Information
Processing Time:
2-3 days
Specs
Country of Origin:
MX
Manufacturer Name:
254TTDBD6076
Manufacturer Part Number:
MARATHON MOTORS
