Description
General Purpose Motor Single Phase Motor Design Capacitor-Start/Run 1 HP Nameplate RPM 1 725 No of Speeds 1 Voltage 115/208-230V AC Full Load Amps 8.
4/4.
6-4.
2 A 56HZ Frame Hz 60 Hz Motor Service Factor 1.
15 Max Ambient Temp 104 Degrees F Motor Thermal Protection None Duty Cycle Continuous Ins.
Class B Motor Enclosure Design Open Dripproof Motor Shaft Rotation CW/CCW Motor Mounting Type Rigid Base Motor Mounting Position All Angle Inverter Rated No Motor Shaft Design Keyed
