General Purpose Motor Single Phase Motor Design Capacitor-Start/Run 1/3 HP Nameplate RPM 1 725 No of Speeds 1 Voltage 115/208-230V AC Full Load Amps 3.
8/1.
9-1.
9 A 48 Frame Hz 60 Hz Motor Service Factor 1.
35 Max Ambient Temp 104 Degrees F Motor Thermal Protection None Duty Cycle Continuous Ins.
Class B Motor Enclosure Design Open Dripproof Motor Shaft Rotation CW/CCW Motor Mounting Type Rigid Base Motor Mounting Position Horizontal or Vertical Shaft Down Inverter Rated No
Features
Extra Information
Processing Time:
2-3 days
