JOHNSON CONTROLS VA9208-GGA-2 - ELECTRIC VALVE ACTUATOR PROPORTIONAL 24V - ELECTRIC BALL VALVE ACTUATOR VOLTAGE 24 SIGNAL TYPE PROPORTIONAL TORQUE 70 IN.
-LB.
CYCLE TIME 150 SEC.
AMBIENT TEMP RANGE -40 DEGREES TO 140 DEGREES F TYPE OF ACTUATOR SPRING RETURN STROKE DEG.
95 HEIGHT 3-13/32 IN.
WIDTH 3-29/32 IN.
DEPTH 7-13/32 IN.
ELECTRICAL CONNECTIONS CABLE POWER CONSUMPTION 7.
9 VA ENCLOSURE RATING NEMA 2 DIRECT MOUNT MOUNTING FOR USE WITH JCI VG1000 BALL VALVE INCLUDES FACTORY MOUNTED VALVE LINKAGE STANDARDS UL CE C-TICK - EQUAL TO G6818637
Features
Specs
Manufacturer Name:
JOHNSON CONTROLS
Manufacturer Part Number:
VA9208-GGA-2
