Description
Molded Case Circuit Breaker 15 A Amps AC Voltage Rating 347/600V AC Max AIR Rating 200kA at 240V AC For Use With GE Panelboards Series FBH Circuit Breaker Type Standard Number of Poles 3 DC Voltage Rating Not Rated Terminal Connection Lug Trip Type Thermal Magnetic Phase Three Instantaneous Trip Fixed Phase Connection ABC Frame Size 100A/FB Circuit Breaker Mounting Style Free Standing Height 6.
45 in Width 4.
11 in Depth 3.
88 in Min Wire Size 14 AWG Max Wire Size 10 AWG
Features
Extra Information
Processing Time:
2-3 days
