Description
SQUARE D EDB34060 - BOLT ON CIRCUIT BREAKER 60A 3P 18KA 277V - BOLT ON CIRCUIT BREAKER 60 AMPS NUMBER OF POLES 3 CIRCUIT BREAKER TYPE STANDARD AC VOLTAGE RATING 277/480VAC DC VOLTAGE RATING 125/250VDC FOR USE WITH SQUARE D NF PANELBOARDS SERIES EDB TERMINAL CONNECTION LUG MIN WIRE SIZE 14 AWG (CU) 12 AWG (AL) MAX WIRE SIZE 2/0 AWG LENGTH 5.
66 IN.
WIDTH 3 IN.
DEPTH 4.
05 IN.
STANDARDS UL CSA NOM 117 CERTIFIED - EQUAL TO G2109423
Features
Specs
Manufacturer Name:
SQUARE D
Manufacturer Part Number:
EDB34060
